Body

Dimensions:
249.1*167.8*19.8mm

Weight:

1212g (5G version)
1200g (4G version)

wp30 pro

Storage

RAM&ROM

24GB (12+12) RAM+256GB ROM (5G version)
24GB (8+16) RAM+256GB ROM (4G version)
*Available storage and RAM are less than the total memory due to storage of the operating system and software pre-installed on the device.

RAM Type-
LPDDR4X

ROM Specifications-
UFS2.2 (5G version)
UFS2.1 (4G version)

Phone Storage Card-
Support SD card Up to 1TB

Display

Screen-
10.1-inch
*Measured diagonally, the screen size is 10.1-inch in the full rectangle. Actual display area is slightly smaller.

Screen-to-Body Ratio- 78%

Resolution- 1920*1200

Pixel Density- 225 PPI

Screen Brightness- 400nit typictal

Aspect Ratio- 14.4:9

Contrast- 1000:1

Chips

CPU Model-
Media Dimensity720 (5G version)
MediaTek MT8788 (4G version)

Frequency-
2.0 GHz

Core-
Octa cores

Framework- 5G version:
2*2.0 GHz Cortex-A76
6*2.0 GHz Cortex-A55
4G version:
4*2.0 GHz Cortex-A73
4*2.0GHz Cortex-A53

Technology-
7 nanometers (5G version)
12 nanometers (4G version)

GPU Model-
Arm Mali-G57 MC3 (5G version)
Arm Mali-G72 MP3 (4G version)

ANTUTU 10 Score-
370000 (5G version)
260229 (4G version)

Battery

Capacity- 32000mAh

Material- Polymer

Standby time-
2720 hrs (5G version)
3500 hrs (4G version)

Music time-
85 hrs (5G version)
75 hrs (4G version)

Video time-
35 hrs (5G version)
31 hrs (4G version)

Calling time-
220 hrs (5G version)
183 hrs (4G version)

Gaming time-
35 hrs (5G version)
30 hrs (4G version)

Browsing time- 45 hrs

Charging time- 6 hrs

Charging Power- 33W

Reverse Charging- Support

Front Camera

Pixel- 32MP

Sensor- Sumsung @S5KGD1SP03

Optical Dimension- 1/2.8"

Aperture- F2.2±5%

Wide Angle- 78°

Focusing Type- FF

Shooting Functions- Monochrome Mode, Beauty

Video Record- 1080P@30fps, 720P@30fps, 480@30fps

Main Camera

Pixel- 48MP

Sensor- SONY @IMX582

Sensor size- 1/2"

Aperture- F1.79

Wide Angle- 79.4°

Focusing Type- PDAF

Shooting Functions-
Bokeh, Monochrome Mode, Beauty, Night View, Pro

LED Flash- Supported

Video Record- 1080P@30fps, 720P@30fps, 480@30fps

Night Vision Camera

Pixel- 20MP

Sensor- SONY @IMX350

Sensor size- 1.278"

Aperture- F1.8

Wide Angle- 78.5°

Focusing Type- AF

Shooting Functions- Night vision

LED Flash- Infrared fill light

Macro Camera

Pixel- 2MP

Sensor- BYD @BF2253L

Sensor size- 1/5"

Aperture- F2.4

Wide Angle- 84°

Focusing Type- FF

Shooting Functions- Macro

Connectivity

Wi-Fi- IEEE802.11 a/b/g/n/ac 2.4/5G

Bluetooth- 5.1

USB- Type-C

GPS- GPS, GLONASS, Galileo, Beidou

OTG- Support

HDMI-
N/A (5G version)
Support (4G version)

Sensors

G-sensor- Support

Gyroscope- Support

Ambient Light Senor- Support

Compass (magnetic)- Support

NFC- Support

Hard Coulometer- Support

Sound Amplifier- AW88394*2

System

Operating System- Android 13.0

FOTA Upgrade- Support

Network

SIM Cards Inserting Mode- Nano+Nano/Nano+TF

Network Type-
GSM+CDMA+WCDMA+FDD+TDD+NR (5G version)
GSM+WCDMA+FDD+TDD (4G version)

Frequency-
GSM:B2/B3/B5/B8
CDMA:BC0/BC1/BC10
WCDMA:B1/B2/B4/B5/B8/B6/B19

FDD:
B1/B2/B3/B4/B5/B7/B8/B12/B13/B17/B18/B19/B20/B25/B26/B28A/B28B/B66/
TDD:B34/B38/B39/B40/B41
NR：n1/3/5/8/20/28/38/41/77/78 (5G version)

GSM:B2/B3/B5/B8

WCDMA:B1/B2/B4/B5/B8

FDD: B1/B2/B3/B4/B5/B7/B8/B12/B17/B18/B19/B20/B25/B26/B28A/B28B/B66

TDD:B38/B39/B40/B41/ (4G version)

EDGE/GPRS- Support

Ruggedness

MIL-STD-810H
Rated IP68
Rated IP69K
